Mineral Hydraulic HLP 10

Mineral Hydraulic HLP 10 is an optimally alloyed hydraulic oil. It has a high level of performance and a wide range of applications throughout the industry. It offers excellent wear protection under extreme loads. Mineral Hydraulic HLP 10 is particularly characterized by good viscosity-temperature behavior, high resistance to aging and reliable protection against corrosion.

Mineral Hydraulic HLP 10 product data sheet
Mineral Hydraulic HLP 10 safety data sheet

Category:

Description

TIPP OIL Mineral Hydraulic HLP 10 is an optimally alloyed hydraulic oil. It has a high level of performance and a wide range of applications throughout the industry. It offers excellent wear protection under extreme loads. Mineral Hydraulic HLP 10 is particularly characterized by good viscosity-temperature behavior, high resistance to aging and reliable protection against corrosion.

Instructions for use

TIPP-OIL Mineral Hydraulic HLP 10 is suitable for all types of industrial and mobile hydraulic systems

Specification:

  • AFNOR NF E 48-603 HM
  • ASTM D6158
  • CETOP RP 91H HM
  • DIN 51524-2
  • ISO 11158 HM
  • ISO 6743-4 HM
  • SAE MS1004 HM
  • VDMA 24318

Recommendation

  • Bosch Rexroth RE 90220
  • Danieli Hydraulics
  • Metso
  • Sauer-Danfoss 520L0463

Characteristics

  • High resistance to aging
  • Neutrality towards sealing materials
  • Extensive protection against wear, corrosion and foaming
  • Very stable and excellent viscosity and temperature behavior

Technical specifications

 Properties  Data  unit  testing under
 Kinematic Viscosity at 40°C    10,0  MM²/S  ISO 51562-2
 Kinematic Viscosity at 100°C     2,7  MM²/S  ISO 51562-2
 viscosity index  110  ISO 2909
 Appearance  COLOURLESS  visually
 Density at 15°C  836,0  KG/M³  DIN 51 757
 pour point  -51  °C  ISO 3016



All data given are approximate values and are subject to normal production fluctuations. To the best of our knowledge, all information corresponds to the current state of knowledge and our development. We reserve the right to make changes. All references to DIN standards are only used to describe the goods and do not constitute a guarantee. In the event of problems, request technical advice.
