Mineral Hydraulic HLP 320

Mineral Hydraulic HLP 320 is an optimally alloyed hydraulic oil. There is a high level of performance and a wide range of applications in the industry as a whole has.

Mineral Hydraulic HLP 320 product data sheet
Mineral Hydraulic HLP 320 safety data sheet

Category:

Description

TIPP-OIL Mineral Hydraulic HLP 320 is a mineral-based hydraulic fluid with highly effective additives. It is optimum alloyed and is having a high efficiency and a wide range of application within the whole industry. Mineral Hydraulic HLP 320 offers effective additives with a high level of wear protection even under extreme loads. Mineral Hydraulic HLP 320 characterized by a very good viscosity - temperature behaviour, high ageing stability and reliable corrosion protection.

Instructions for use

TIPP-OIL Mineral hydraulic HLP 320 is universal in all hydraulic systems. There are systems with high pressure is recommended for highly stressed hydraulic pumps of all types, in-sensitive controls, but also for the supply of small gears and for use in circulation systems.

specifications

  • AFNOR NF E 48-603HM
  • ASTM D6158
  • CETOP RP91H HM
  • DIN 51524-2
  • GB 111118.1 L-HM (conventional)
  • ISO 11158 HM
  • ISO 6743-4HM
  • JCMAS HK
  • MIL-PRF-17672E
  • SAE MS1004HM
  • SEB 181 222

Recommendation

  • VDMA 24318
  • Atos
  • Bosch Rexroth RE 90220
  • Danieli Hydraulic
  • Denison HF-0/HF-1/HF-2
  • Eaton/Sperry Vickers I-286-S
  • Eaton/Sperry Vickers M-2950-S
  • Fives Cincinnati P-38/P-68
  • GM LH-02-1-04, GM LS-2
  • Metso ͻMüller Weingarten
  • Sauer-Danfoss 520L0463
  • US steel 126/127/136
  • Voith Turbo (HLP 32)

Characteristics

  • Reliable protection against corrosion
  • Very good oxidation stability
  • Neutral fabrics to seal
  • Excellent wear protection
  • High resistance to aging

Technical specifications

 Properties  Data  unit  testing under
 Kinematic Viscosity at 40°C    32,0  MM²/S  ISO 51562-2
 Kinematic Viscosity at 100°C     5,6  MM²/S  ISO 51562-2
 viscosity index  115  ISO 2909
 Appearance  YELLOW  visually
 Density at 15°C  859,0  KG/M³  DIN 51 757
 pour point  -33  °C  ISO 3016



All data given are approximate values and are subject to normal production fluctuations. To the best of our knowledge, all information corresponds to the current state of knowledge and our development. We reserve the right to make changes. All references to DIN standards are only used to describe the goods and do not constitute a guarantee. In the event of problems, request technical advice.
