Dexron D II Red

Dexron D II Red ist ein sehr hochwertiges Getriebeöl für Automatikgetriebe aller Fahrzeuge und Maschinen.

Dexron D II (rot) Produktdatenblatt
Dexron D II (red) safety data sheet

Description

TIPP-OIL Dexron D II RED is a very high-quality transmission liquid for automatic transmissions of all vehicles and work machines. It was made on the Basis of highly refined mineral oils with the corresponding additives. In addition, it has been specifically developed for the stated specifications and applications. Dexron D II RED meets Maximum lubrication and wear protection by special additives.

Instructions for use

TIPP-OIL Dexron D II RED was developed for use in automatic Transmissions, hydraulic steering systems, converters, and power transmission and can be used as a Universal ATF (Automatic-Transmission-Fluid) for all vehicles and work machines. It is recommended that if an ATF type Dexron D II is to be used according to the manufacturer's specifications. The operating instructions of the Vehicle and engine manufacturers are to be observed.

Quality classification specification

  • GM Dexron® II D

Recommendation

  • Caterpillar TO-2
  • Ford ESP-M2C166-H, Ford WSS-M2C185-A
  • Ford MERCON®
  • Ford SQM-2C9010-B, Ford WSS-M2C138-CJ
  • MAN 339 type Z1
  • MB 236.2, MB 236.6, MB 236.7
  • Renk Doromat
  • VOITH H 55.6335.XX
  • ZF TE-ML 11A/14A/17C/03D/04D/05L

Characteristics

  • Foam of freedom even under the heaviest of loads
  • Thermally extremely high load capacity
  • Miscible and compatibility with all brands of ATF's
  • Neutral behaviour towards sealing materials
  • Reliable protection against wear, sludge formation, bonding and corrosion
  • Stable and excellent viscosity-temperature behavior
  • Problem of freedom, both at very low and high temperatures

Technical specifications

 Properties  Data  unit  testing under
 Kinematic Viscosity at 40°C   35,0  MM²/S  ISO 51562-2
 Kinematic Viscosity at 100°C    7,2  MM²/S  ISO 51562-2
 viscosity index  176  ISO 2909
 Appearance  RED  visually
 Density at 15°C  852,0  KG/M³  DIN 51 757
 pour point  -54  °C  ISO 3016



All data given are approximate values and are subject to normal production fluctuations. To the best of our knowledge, all information corresponds to the current state of knowledge and our development. We reserve the right to make changes. All references to DIN standards are only used to describe the goods and do not constitute a guarantee. In the event of problems, request technical advice.
